"This PLA is a multi-purpose, floor-standing unit that is suitable for various applications" "It is 1250mm in height, 1250mm in width, and 620mm in depth, and is made from polyester reinforced with fiberglass, giving it durability and resistance to harsh environments" "The enclosure is available in grey (RAL 7035) and consists of two side parts, two plain front doors, and two rear panels" "The doors can be opened up to 120°, from both the right and left sides, and feature a four-point lock with a 5mm double-bar insert" "The doors and rear panels are also removable for maintenance purposes" "The enclosure offers robust protection against various hazards, including fire, impacts, dust, and water" "It can withstand fire up to 960°C in accordance with the IEC 62208 standard" "It has an IK10 rating (IEC 62262) for high impact resistance and an IP65 rating (IEC 60529) for complete dust and water protection" "Additionally, the enclosure has class II electrical insulation to prevent electric shocks and allow for the building of totally insulated solutions" "It is UL/cUL listed, Veritas certified, and DNV Marine approved, and can be stored in ambient air temperatures ranging from -35°C to 90°C without affecting its performance"

Brand

Schneider Electric

Range

PanelSeT PLA

Part No

NSYPLA12126G

Weight (kg)

72.00 kg

Type

Thalassa PLA

With mounting plate

FALSE

With glazed door

FALSE

Wall fastening possible

FALSE

Suitable for metrical mounting

FALSE

RAL-number

7035

Tackable

TRUE

Height

1250

Degree of protection (IP)

IP65

Pitched roof

FALSE

Colour

Grey

Width

1250

Surface finishing

Untreated

Material

Plastic

Number of doors

2

Suitable for outdoor set-up

TRUE

Number of locks

2

Material quality

Polyester

Wall build in

FALSE

Depth

620

Mounting plate depth-adjustable

FALSE

Impact strength

IK10

With ventilation door

FALSE

EMC-version

FALSE

Degree of protection (NEMA)

13

Pole fastening

FALSE

With backside door

FALSE

Floor installation possible

TRUE
