Harmony K1, K2, Cam changeover switch, 3 poles, with off position, 60° switching angle, 32 A, multi-fixing - Schneider Electric - K30F003UP

Harmony K1, K2, Cam changeover switch, 3 poles, with off position, 60° switching angle, 32 A, multi-fixing - Schneider Electric - K30F003UP

K30F003UP

Harmony K1, K2, Cam changeover switch, 3 poles, with off position, 60° switching angle, 32 A, multi-fixing - Schneider Electric - K30F003UP

Control

~~List Price £72.31 +VAT~~

Our Price £54.23 +VAT

SAVE 26% OFF List Price

Estimated delivery between 7-10 working days

This Harmony K30 complete cam switch/selector switch has 3 poles (3P). It also has a rating of 32A, a screw clamp mounting mode and a metallic color with black marking. It has "1 - 0 - 2" marking to indicate the position of the switch. This metal head complete cam switch/selector switch is designed to meet most industrial and process control application thanks to a compact size, an easy integration with 16mm and 22mm diameter units and has several selection functions. It has a 60 degree between its switching positions.

Brand: Schneider Electric
Range: Harmony K
Part No: K30F003UP
Weight (kg): 0.28 kg
Type: Harmony K
Type of electrical connection of main circuit: Screw connection
With 0 (off) position: TRUE
With retraction in 0-position: FALSE
Type of control element: Long turning handle
Model: Reverser
Material housing: Other
Degree of protection (IP), front side: IP40
Rated permanent current Iu: 32
Complete device in housing: TRUE
Suitable for front mounting 4-hole: TRUE
Number of poles: 3
Degree of protection (NEMA), front side: Other
Suitable for distribution board installation: FALSE
Suitable for intermediate mounting: TRUE
Suitable for ground mounting: FALSE

Datasheet for K30F003UP - Harmony K1, K2, Cam changeover switch, 3 poles, with off position, 60° switching angle, 32 A, multi-fixing - Schneider Electric - K30F003UP

Download
