This XMLG Pressure Transmitter is a part of the OsiSense XM product range of pressure transmitters and switches. This pressure transmitter controls or regulates pressure levels in air and fresh water and is used for pumping applications. A pressure transmitter transforms measured pressure into a proportional analog output. The range of this transmitter is 0psi to 200psi and the current output is 4mA to 20mA. The transmitter accepts 24VDC power. The transmitter has a DIN 43650A connector and a 1/4in NPT male fluid connection. It is compliant with CE, IEC, RCM, EAC, UL, and CSA standards and IP65 and NEMA 4 rated. This "TQ" part is a bulk pack of 25. It is suitable for monitoring air, fresh water, hydraulic oils and refrigeration fluids. This product is certified by CSA C22.2 No 14, EAC, RCM and UL 508. It meets CE and EN/IEC 61326-2-3 standards. It is sold in sets of 25. One of the most comprehensive catalogues of industrial and power pressure sensors on the market. The line of XM Pressure Sensors and Switches (formerly known as OsiSense) combine the latest pressure sensing technology with adaptability to virtually any configuration.

Brand

Telemecanique Sensors

Range

pressure sensors XM

Part No

XMLK200P2C23TQ

Weight (kg)

0.11 kg

Type

pressure sensors XM
