XUVU06M3NSNM8

ultrasonic sensor label fork 60x3 - 12..24 V DC - NPN NO/NC connect M8 - Telemecanique Sensors - XUVU06M3NSNM8

Control

~~List Price £370.46 +VAT~~

Our Price £277.85 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

Get in touch

This product is part of the XU range, an offer of photoelectric sensors. This ultrasonic sensor has a fork design and a thru-beam detection system. This photoelectric sensor has a numeric potentiometer setting-up, 2 LEDs for output state, adjustment mode and keypad locking. With an accuracy of ±0.20mm at 120m/min. It is furnished with 4-pin M8 male connector for electrical connection and 4-wire 1 normally open or 1 normally closed programmable NPN solid state discrete output. It is a photoelectric sensor with a rated supply voltage of 12V to 24V DC with reverse polarity protection and a switching frequency of ≤1500Hz. It is an IP65 rated product. The enclosure is made of zinc alloy with PC lens. Its dimensions are 18mm (Width) x 47mm (Depth) x 92.5mm (Height) and weighs 0.13kg. It is ideal for material handling, packaging, labelling, assembly, lift, escalators or food and beverage industries. It is ideal for detection of transparent labels. This product is certified by CE and CULus.

Brand: Telemecanique Sensors
Range: Photoelectric sensors XU
Part No: XUVU06M3NSNM8
Weight (kg): 0.16 kg
Type: Photoelectric sensors XU
